| Place of Origin: | China |
|---|---|
| Minimum Order Quantity: | 1 set |
| Delivery Time: | Peak Season Lead Time: within 15 workdays, Off Season Lead Time: within 15 workdays |
| Payment Terms: | LC, T/T |
| Model NO.: | CPD40 | Type: | Electric Forklift |
|---|---|---|---|
| Power: | AC Motor | Load Capacity: | 1T - 5T |
| Fuel: | Electric | Load Center: | 500mm |
| Lift Height: | >5000mm | Condition: | New |
| Battery: | Lead Acid And Lithium | Capacity: | 4000 Kgs |
| Weight: | 4500 Kgs | Turning Radius: | 2545 |
| Min Right Angle Aisle Width: | 4345 | Battery Capacity: | 80V/500ah |
| Lifting Motor: | 20kw | Transport Package: | Standard Sea Freight Packing |
| Specification: | Steel+rubber | Trademark: | OMFT |
| Origin: | China | HS Code: | 8427109000 |
| Supply Ability: | 7000 PCS/Year | Package Size: | 2730.00cm * 1290.00cm * 2100.00cm |
| Package Gross Weight: | 4500.000kg | Customization: | Available |
| After-sales Service: | Lifetime Service | Warranty: | 24months Or 4000hours |
| Shipping Cost: | Contact The Supplier About Freight And Estimated Delivery Time. | : | Support Payment In USD |
| Secure Payments: | Every Payment You Make At Made-in-china.com Is Protected By The Platform. | Refund Policy: | Claim A Refund If Your Order Doesn't Ship, Is Missing, Or Arrives With Product Issues. |
| Main characteristics | Model | CPD40 4ton electric forklift with 3m duplex mast, AC motors and control, with charger, 1070mm fork | |
| Power Type | / | Electric | |
| Opreation | Rider | ||
| Rated Capacity | mm | 4000 | |
| Load Centre | mm | 500 | |
| Wheel base | mm | 1880 | |
| Wheel Specification | Material | mm | Rubber |
| Front tyre | mm | 28*9-15 | |
| Rear tyre | mm | 18*7-8 | |
| Wheel distance /front | mm | 1880 | |
| size | Mast Tilt Angle (F/R) | mm | 6°/12° |
| Lift Height | mm | 3000 | |
| Over head guard height | mm | 2180 | |
| Mast Lowered Height | mm | 2100 | |
| Distance from seat to overhead guard | mm | 1030 | |
| Overall width | mm | 1290 | |
| overall length(with fork) ) | mm | 3840 | |
| overall length(without fork) | mm | 2730 | |
| Fork size | mm | 1070×120×45 | |
| Turning Radius | mm | 2545 | |
| Min right angle aisle width | mm | 4345 | |
| Performance parameter | Travel speed (Empty load/Full load) | km/h | 13/12 |
| Lifting speed (Empty load/Full load) | mm | 340/280 | |
| Max.Gradeabllity | mm | 12° | |
| Min height | mm | 2100 | |
| Controller | / | AC | |
| Brake mode | Manual | ||
| Motor Battery | Battery | KW | 80V/500AH |
| Driving Motor | KW | 12.5 | |
| Lifting Motor | KW | 20 | |
