| Place of Origin: | China |
|---|---|
| Minimum Order Quantity: | 1 set |
| Delivery Time: | Peak Season Lead Time: within 15 workdays, Off Season Lead Time: within 15 workdays |
| Payment Terms: | LC, T/T |
| Model NO.: | CPD10 | Lift Height: | 3000~7000mm |
|---|---|---|---|
| Condition: | New | Min. Turning Radius: | 1425mm |
| Min. Width Of Right Angle Stacking: | 2931mm | Standard: | Ce ISO SGS |
| Fork: | 1070mm | Tyre: | Pneumatic Or Solid |
| Control: | Curtis Zapi Sme | Battery: | 24V/270ah |
| Capacity: | 1000kgs | Battery Charger: | Free |
| OEM And Spare Parts: | Available | Transport Package: | Standard Sea Freight Packing |
| Specification: | Steel+rubber | Trademark: | OMFT |
| Origin: | China | HS Code: | 842710 |
| Supply Ability: | 7000 PCS/Year |
| (Model No.) | unit | CPD10A-30 |
| (Capacity) | Kg | 1000 |
| Mast | duplex | |
| (Max lifting height) | H(mm) | 3000 |
| (Load center) | C(mm) | 500 |
| (Wheel type) | Rubber | |
| (Fork size) | (mm) | 1070*100*35 |
| Fork adjust range | (mm) | 210-566 |
| (Overall length ) | L(mm) | 1587 |
| (Overall width) | S(mm) | 850 |
| (Height--Mast Lowered) | H1(mm) | 2035 |
| (Height--Mast lifted) | H2(mm) | 3918 |
| Mast Tile angle | 2/4 | |
| Over head guard height | H3(mm) | 1995 |
| (Turning radius) | WQ(mm) | 1425 |
| Min. Width of Right Angle Stacking | (mm) | 2931 |
| (Max.Walking Speed) | Km/h | 5.0/5.2 |
| (Grade ability) | % | 6/8 |
| (Total Weight) | Kg | 1780 |
| (Driving wheel) | mm | Ø230*75 |
| (Front wheel) | mm | Ø305*127 |
| (wheel base) | mm | 1130 |
| (Battery capacity) | V/Ah | 24/270 |
| Charger | V/Ah | 24/30 |
| (Driving motor) | Kw | 2.5 |
| (Lifting motor) | Kw | 2.2 |
