| Model NO.: | CPQY60 | Type: | Gasoline And LPG Dual Fuel Forklift |
|---|---|---|---|
| Power: | Gasoline Engine | Load Capacity: | 6000kgs |
| Fuel: | Gasoline And LPG Dual Fuel Forklift | Load Center: | 600mm |
| Lift Height: | 3000~7000mm | Condition: | New |
| Min. Turning Radius: | 3250mm | Min. Width Of Right Angle Stacking: | 2960mm |
| Standard: | Ce ISO SGS | Fork: | 1070mm |
| Tires: | Pneumatic Or Solid | Engine: | Us GM Psi |
| Emission Standard: | Euro And Us EPA | OEM And Spare Parts: | Available |
| Front Overhang: | 590mm | Max.Gradeability: | 20% |
| Transport Package: | Standard Sea Freight Packing | Specification: | Steel+rubber |
| Trademark: | OMFT | Origin: | China |
| HS Code: | 842720 | Supply Ability: | 7000 PCS/Year |
| Package Size: | 4000.00cm * 1500.00cm * 2100.00cm | Package Gross Weight: | 8000.000kg |
| Model | FY50 | FY60 | FY70 | ||
| Power Type | LPG | LPG | LPG | ||
| Drive Type | Sit | Sit | Sit | ||
| Load Capacity | kg | 5000 | 6000 | 7000 | |
| Load centre | mm | 600 | 600 | 600 | |
| Tyre | |||||
| Tyre Type | Pneumatic Tyre | Pneumatic Tyre | Pneumatic Tyre | ||
| Front Tyre | 8.25-15-14PR | 8.25-15-14PR | 8.25-15-14PR | ||
| Rear Tyre | 8.25-15-14PR | 8.25-15-14PR | 8.25-15-14PR | ||
| Overall Dimension | |||||
| Lift Height | mm | 3000 | 3000 | 3000 | |
| Fork Size | L×W×T | mm | 1220×150×60 | 1220×150×60 | 1220×150×70 |
| Mast Tilt Angle | F/R | . | 6/12 | 6/12 | 6/12 |
| Mast Lowered Height | mm | 2500 | 2500 | 2500 | |
| Mast Extended Height(with backrest) | mm | 4415 | 4415 | 4415 | |
| Length to face of fork(Without fork) | mm | 3450 | 3450 | 3560 | |
| Overall Width | mm | 2010 | 2010 | 2010 | |
| Overhead Guard Height | mm | 2470 | 2470 | 2470 | |
