Detail Information

Model NO.:	CBD15A	Type:	Powered Pallet Truck
Power:	DC Motor	Load Capacity:	1000-1500kgs
Fuel:	Electric	Load Center:	600mm
Lift Height:	205mm	Condition:	New
Certificate:	Ce ISO SGS	Fork Size:	1150/1200mm
The Wheelbase:	1305mm	Speed:	4km/H
OEM And Spare Parts:	Available	Minimum Outside Turning Radius:	1595mm
Color:	Orange Or Customized	Transport Package:	Pallet
Specification:	Steel+rubber	Trademark:	OMFT
Origin:	China	HS Code:	842710
Supply Ability:	7000 PCS/Year	Package Size:	1830.00cm * 700.00cm * 650.00cm
Package Gross Weight:	210.000kg

Product Description

1.5ton Small Mini Electric Pallet Truck with Battery and Charger Tcm/Linde/Yale/Toyota/Crown/Hyster/Heli/Ep

Model		CBD15
Load capacity	kg	1500
Load center	mm	600
Wheel base	mm	1303
Operating type		Walkie
Wheels
(/) Wheels type		PU
// Wheel quantity Driving wheel/Balance wheel /Bearing wheel		1/0/4
Driving wheel size	mm	¢210*70
Balance wheel size	mm	¢84×70 (/Double wheels)
Bearing wheel size	mm	¢80*17
Dimension
Min.fork lowered height	mm	85
Max.fork lifting height	mm	205
Max.lifting height	mm	120
Outside width between forks	mm	550//685
Inside width between forks		230/365
Fork length	mm	1150/1200
Fork width	mm	160
Fork thickness	mm	55
,/ Overall length	mm	1826
Overall width	mm	698
() Overall height(With handle)	mm	1294
() Overall height(Without handle)	mm	648
,/ Min.Turning radius	mm	1593
,/ (800×1200,1200) Min.Aisle width for pallets 800×1200	mm	1939
,/ (1000×1200,1200) Min.Aisle width for pallets 1000×1200	mm	1972
Performance
,/ Travel speed,laden/unladen	km/h	3/4
,/ Lift speed,laden/unladen	mm/s	35/40
,/ Lowering speed,laden/unladen	mm/s	75/60
,/ Gradeability,laden/unladen	%	5/7
Electrical configuration
Drive motor	KW	DC 0.65
Lift motor	KW	DC 0.8
/ Battery voltage / capacity	V/Ah	24/85
Brake		/ Electromagnetic / Regenerative
Controller		CURTIS1212P
Weight
Battery weight	kg	48
()Service weight with battery	kg	260

ADVANTAGES:1.5Ton 150 Kg 1.5T Electric Hand Pallet Truck Jack with Ce ISO
1.High efficiency permanent magnet drive motor, strong power.
2.High performance hydraulic station, low noise, smooth operation, high efficiency.
3. Economic and energy saving, low maintenance cost, an ideal alternative to the manual handling truck;
4. Long handle, labor saving and easy control.
5. Enhanced fork design, sturdy and durable.
6. Can add the load-backrest; ensure the safety of goods and people.
7. 24V/75Ah(A)/80A(B) lead-acid battery, maintenance-free, can meet the needs of different customers.
8. Built-in charger, more convenient.
9. Compact and flexible, easy to operate, widely used in narrow aisle workshop, supermarket & cargo container.

Electric Pallet Truck 1.5ton for Tcm/Linde/Yale/Toyota/Crown/Hyster/Heli/Ep Fuel Electric 6

WHY CHOOSE US?
1.Strong production, research and development, after-sales capacity
We have 35, 000 square meters workshop and 100 R&D staff. We have been specializing in the forklift industry for more than 20 years. 20,000 units production capacity per year. OEM is also welcomed.

2.High quality source of raw materials and spare parts
Our spare parts and steel are all from well-known manufacturers at home and abroad with reliable quality. Besides, we are very professional in painting, welding and other production processes. Our products are both excellent in appearance and internal structure.

3.Competitive price and fast delivery
For standard forklift, normally we have them in store. If not, we can finish production within 1 week. Even for high mast and other non-standard forklift,we can finish production within 2 weeks. Our price is transparent and competitive. We are not the cheapest in the market, but we ensure you that our products worth every penny.

4.Professional technical guidance and use training
We have detailed operation instructions and video instructions for each product. If you have any question during the use, please feel free to contact us. We have professional personnel to answer them one by one.

5.Warranty and after-sales service
2000h or 2 years warranty time. Free parts change during warranty time.
Strict quality testing was conducted for each truck before shipping to ensure the safety of users.
In order to ensure our customer has a good using feeling, we send some spare parts for free with every forklift, eg: filters, seal, cylinder, etc.
In future, if customers need any spare parts, we will arrange shipping within 48h.

6.Complete product line
Diesel Forklift:1.5ton; 2ton; 2.5ton;3ton; 3.5ton; 3.8ton; 4ton; 4.5ton; 5ton; 6ton; 7ton; 8ton; 10ton; 12ton; 14ton; 15ton;16ton; 25ton; 28ton; 33ton; 42ton;45ton;48ton.
LPG&Gasoline Forklift :1.5ton; 2ton; 2.5ton;3ton; 3.5ton; 4ton; 5ton; 6ton; 7ton.
Electric Forklift: 1ton; 1.5ton; 2ton; 2.5ton;3ton; 3.5ton; 4ton; 5ton; 6ton.
Warehouse and material handling equipment: Manual hand pallet truck; electric pallet truck; electric pallet stacker; electric reach stacker; VNA(very narrow aisle) 3way or 4ways stacker; tow tractor; AGV equipments
Aerial platform:Scissor lifting platform 3.9M; 5.8M; 8M;10M;12M;14M
Rough terrain Off-road forklift and side forklift truck: 2ton to 12 ton

7.Logistics
It doesn't matter whether you have import qualification or not, we can solve the logistics problem for you. We have reliable logistics team and can send the goods directly to your warehouse if you need.
Also, we can do FOB, CIF and FCA term as you required.
Electric Pallet Truck 1.5ton for Tcm/Linde/Yale/Toyota/Crown/Hyster/Heli/Ep Fuel Electric 7

Place of Origin:	China

Minimum Order Quantity:	1 set
Delivery Time:	Peak Season Lead Time: within 15 workdays, Off Season Lead Time: within 15 workdays
Payment Terms:	LC, T/T
