Detail Information

Model NO.:	CQDS	Type:	Stacker
Power:	AC Motor	Load Capacity:	1000~1500kgs
Fuel:	Electric	Load Center:	500mm
Lift Height:	6000~12000mm	Condition:	New
Travel Speed(Laden/Unladen):	7/8km/H	Standard:	CE ISO SGS
Battery:	48V/300ah(1.5ton)~48V/400ah(2ton)	Min. Turning Radius:	1905(1.5ton)~2000(2ton)mm
Min. Width Of Right Angle Stacking:	2900mm	Fork:	1070X100X35(1.5ton)~1070X100X35(2ton)mm
Battery Charger:	Free	OEM And Spare Parts:	Available
Transport Package:	Standard Sea Freight Packing	Specification:	Steel+PU
Trademark:	OMFT	Origin:	China
HS Code:	842710	Supply Ability:	500 PCS/Year
Package Size:	2550.00cm * 1690.00cm * 2100.00cm	Package Gross Weight:	3500.000kg

Product Description

4-Direction 1t 1.5t 2t 2.5t 3ton Very Narrow Aisle Electric Reach Truck Stacker with Battery Charger 3m~12m Tcm/Linde/Yale/Toyota/Crown/Hyster/Heli/Ep/Hangcha

model	CQD30SE-40S
capacity	3000
load center	500
Front overhang	240
wheel base	1920
weight	5800
tyre	PU
front tyre	φ280*135
drive tyre	φ382*142
mast closed height	2100
free lifting height	1500
lifting height	4000
max height	5010
over head guard	2180
fork height	45
/ / tile front/rear	3/5
length	2400
fork size	45/125/1070
fork size adjustment	260-700
reach distance	720
()ground clearance	80
,1000×1200(1200)Stacking channel width, pallet 1000×1200 (1200 cross fork placement)	3000
minimum turning radius	2240
,/ Travel speed, no load/full load	8/7
,/ Lift speed, no load/full load	0.240/0.220
,/ Rate of descent, no load/full load	0.240/0.260
,/ Maximum climbing capacity, no load/full load	≤10
brake	electromagnetism
drive motor rate	6.5
lift motor rate	8.6
battery model	lead acid
/ volt and capacity of battery	48V400Ah
charger	48V/50A
motor	AC
EN12053 noise	75

WHY CHOOSE US?
1.Strong production, research and development, after-sales capacity
We have 35, 000 square meters workshop and 100 R&D staff. We have been specializing in the forklift industry for more than 20 years. 20,000 units production capacity per year. OEM is also welcomed.

2.High quality source of raw materials and spare parts
Our spare parts and steel are all from well-known manufacturers at home and abroad with reliable quality. Besides, we are very professional in painting, welding and other production processes. Our products are both excellent in appearance and internal structure.

3.Competitive price and fast delivery
For standard forklift, normally we have them in store. If not, we can finish production within 1 week. Even for high mast and other non-standard forklift,we can finish production within 2 weeks. Our price is transparent and competitive. We are not the cheapest in the market, but we ensure you that our products worth every penny.

4.Professional technical guidance and use training
We have detailed operation instructions and video instructions for each product. If you have any question during the use, please feel free to contact us. We have professional personnel to answer them one by one.

5.Warranty and after-sales service
2000h or 2 years warranty time. Free parts change during warranty time.
Strict quality testing was conducted for each truck before shipping to ensure the safety of users.
In order to ensure our customer has a good using feeling, we send some spare parts for free with every forklift, eg: filters, seal, cylinder, etc.
In future, if customers need any spare parts, we will arrange shipping within 48h.

6.Complete product line
Diesel Forklift:1.5ton; 2ton; 2.5ton;3ton; 3.5ton; 3.8ton; 4ton; 4.5ton; 5ton; 6ton; 7ton; 8ton; 10ton; 12ton; 14ton; 15ton;16ton; 25ton; 28ton; 33ton; 42ton;45ton;48ton.
LPG&Gasoline Forklift :1.5ton; 2ton; 2.5ton;3ton; 3.5ton; 4ton; 5ton; 6ton; 7ton.
Electric Forklift: 1ton; 1.5ton; 2ton; 2.5ton;3ton; 3.5ton; 4ton; 5ton; 6ton.
Warehouse and material handling equipment: Manual hand pallet truck; electric pallet truck; electric pallet stacker; electric reach stacker; VNA(very narrow aisle) 3way or 4ways stacker; tow tractor; AGV equipments
Aerial platform:Scissor lifting platform 3.9M; 5.8M; 8M;10M;12M;14M
Rough terrain Off-road forklift and side forklift truck: 2ton to 12 ton

7.Logistics
It doesn't matter whether you have import qualification or not, we can solve the logistics problem for you. We have reliable logistics team and can send the goods directly to your warehouse if you need.
Also, we can do FOB, CIF and FCA term as you required.
