| Model NO.: | CPCD150 | Type: | Diesel Forklift |
|---|---|---|---|
| Power: | Diesel Engine | Load Capacity: | 12000kgs |
| Fuel: | Diesel | Load Center: | 600mm |
| Lift Height: | 3000~7000mm | Condition: | New |
| Fork: | 1220mm | Tyre: | Pneumatic Or Solid |
| Engine: | Commins/Deutz/Chinese | Standard: | Ce ISO SGS |
| OEM And Spare Parts: | Available | Emission Standard: | Euro II/III/IV And Us EPA |
| Transport Package: | Standard Sea Freight Packing | Specification: | Steel+rubber |
| Trademark: | OMFT | Origin: | China |
| HS Code: | 842720 | Supply Ability: | 100 PCS/Year |
| Package Size: | 5000.00cm * 2000.00cm * 3000.00cm | Package Gross Weight: | 8000.000kg |
| Item | Model | Unit | CPCD120 | CPCD150 | CPCD160 | ||
| 1 | Power Type | Diesel | Diesel | Diesel | |||
| 2 | Rated Capacity | kg | 12000 | 15000 | 16000 | ||
| 3 | Load Centre | mm | 600 | 600 | 600 | ||
| 4 | Max Lifting Height | mm | 3000 | 3000 | 3000 | ||
| 5 | Fork Size | L×W×T | mm | 1220×170×80 | 1800X180X90 | 1800X180X90 | |
| 6 | Mast Tilt Angle | F/R | Deg | 6°/12° | 6°/12° | 6°/12° | |
| 7 | Front Overhang (Wheel center to fork face) | mm | 780 | ||||
| 8 | Ground Clearance(Bottom of mast) | mm | 240 | 250 | 265 | ||
| 9 | Overall Dimension | Length to face of fork(Without fork) | mm | 4450 | 5770 | 5780 | |
| 10 | Overall Length(with fork) | mm | 5800 | 7570 | 7580 | ||
| Overall Width | mm | 2200 | 2750 | 2750 | |||
| 11 | Mast Lowered Height | mm | 2175 | 3500 | 3500 | ||
| 12 | Mast height | mm | 3300 | 3625 | 3625 | ||
| 13 | Overhead Guard Height | mm | 2570 | ||||
| 14 | Turning Radius (outside) | mm | 4200 | 5800 | 5800 | ||
| 15 | Speed | Travel (No load) | km/h | 30 | 30 | 30 | |
| 16 | |||||||
| Lifting(Full load) | mm/s | 290 | 300 | 300 | |||
| 17 | Max.Gradeability (No load/Full load) | % | 20 | 20 | 20 | ||
| 18 | Tire | Front | mm | 9.00-20-14PR | 4X12.00-24/18PR | 4X12.00-24/18PR | |
| 19 | Rear | mm | 9.00-20-14PR | 2X12.00-20/18PR | 2X12.00-20/18PR | ||
| 20 | Wheel Tread | Front | mm | 1600 | 2060 | 2060 | |
| 21 | Rear | mm | 1700 | 2330 | 2330 | ||
| 22 | Wheelbase | mm | 3000 | 3800 | 3800 | ||
| 23 | Self weight | kg | 13500 | 20000 | 21000 | ||
| 24 | Battery | Voltage/Capacity | V/Ah | 2*12/80 | |||
| 25 | Engine | Model | 6BT5.9-C130 | Cmmins 6BTAA5.9-C190 | Cmmins 6BTAA5.9-C190 | ||
| 26 | Manufacture | Cummins | Cummins | Cummins | |||
| 27 | Rated output/r.p.m. | kw | 97/2200 | 142/2200 | 142/2200 | ||
| 28 | Rated torque/r.p.m. | N·m | 560/1500 | 800/1500 | 800/1500 | ||
| 29 | No.of Cylinder | 6 | |||||
| 30 | Bore×Stroke | mm | 102*120 | ||||
| 31 | Displacement | L | 5.9 | ||||
| 32 | Fuel Tank Capacity | L | 135 | ||||
