Electric Reach Truck Forklift Reach Stacker Truck Fork Lift 3-12m Tcm/Linde/Yale/Toyota/Crown/Hyster/Heli/Ep/Hangcha

Basic Information

Place of Origin:	China

Minimum Order Quantity:	1 set
Delivery Time:	Peak Season Lead Time: within 15 workdays, Off Season Lead Time: within 15 workdays
Payment Terms:	LC, T/T

Get Best Price Contact Now

Detail Information

Model NO.:	CQD	Type:	Stacker
Power:	AC Motor	Load Capacity:	1000kgs~3000kgs
Fuel:	Electric	Load Center:	500mm
Lift Height:	3000~8000mm	Condition:	New
Travel Speed(Laden/Unladen):	10km/H	Standard:	CE ISO SGS
Battery:	48V/300~400ah	Min. Turning Radius:	1710mm
Min. Width Of Right Angle Stacking:	2790mm	Fork:	100/30/1070mm
Battery Charger:	Free	OEM And Spare Parts:	Available
Transport Package:	Standard Sea Freight Packing	Specification:	Steel+PU
Trademark:	OMFT	Origin:	China
HS Code:	842710	Supply Ability:	7000 PCS/Year
Package Size:	2270.00cm * 1098.00cm * 2100.00cm	Package Gross Weight:	3000.000kg

Product Description

Narrow Turning Radius 1t 1.5t 2t 2.5t 3t Electric Reach Truck Forklift Reach Stacker Truck Fork Lift 3~12m Tcm/Linde/Yale/Toyota/Crown/Hyster/Heli/Ep/Hangcha
Stand-On/Seated 48V 1-3Ton AC Motor Battery Reach Electric Forklift for Material Handing
Narrow Turning Radius 1t 1.5t 2t 2.5t Electric Reach Truck Forklift Reach Stacker Truck Fork Lift tcm/linde/yale/toyota/crown/hyster

Optional
Cold refrigeration storage model	Customize other special fork sizes	Customize other colour	1.6M mast; 2.0M mast; 2.5M mast; 3M mast;3.5M mast; 4M mast; 4.5M mast; 5M mast; 5.5M mast; 6M mast	Customize other battery capacity	with side shifter; fork positioner	Fork position LCD display
			Duplex 2tages mast; Triplex 3stages full free mast		with paper roll, bale,carton,block,drum clamp, with push/pull, rotators, multiple loads handlers,carpet boom

Model		CQD15	CQD20
Power type		Battery	Battery
Operate type		Seated	Seated
Load capacity	Q(t)	1500	2000
Load center	C(mm)	500	500
Wheelbase	Y(mm)	1357	1533
Forward distance	Y(mm)	480	650
Service weight	kg	3000	3050
Wheel type		PU	PU
Front wheel	∅×w(mm)	267*114	267*114
Drive wheel	∅×w(mm)	382*142	382*142
Tread,load	b10(mm)	1178	1178
Height-mast closed	h1(mm)	2100	2100
Height-free lift	h2(mm)	1500	1500
Lift height	h3(mm)	4500	4500
Height of mast open(incl. Load-Backrest)	h4(mm)	5085	5085
Overguard height	h14(mm)	2180	2180
Min fork ground clerance	h13(mm)	40	40
Mast tilt forward/backward	°	3/5	3/5
Overall length(with fork)	l2(mm)	2270	2470
Overall width	b1(mm)	1098	1270
Fork size	s/e/l(mm)	35/100/1070	40/122/1070
Fork Adjustable range	b5(mm)	210-705	270-705
Min ground clearance (wheelbase center)	m2(mm)	70	70
Aisle width for pallet 1000*1200 crossway	Ast(mm)	2855	2885
Min turning radius	Wa(mm)	1800	1900
Driving speed(load/unload)	km/h	7.8/6.8	7.8/6.8
Lifting speed(load/unload)	m/s	0.240/0.120	0.240/0.120
Lowering speed(load/unload)	m/s	0.260/0.325	0.270/0.315
Max. climbing ability	%	≤10	≤10
Service Parking		Electromagnetic	Electromagnetic
Drive motor	kw	4.5	6.5
Lift motor	kw	6.3	6.3
Battery type		Lead acid	Lead acid
Battery V/AH	V/Ah	48V300Ah	48V400Ah
Drive motor type		AC	AC
Noise level EN12053	dB(A)	75	75

ADVANTAGES:1.5 Ton 1500 Kg Cqd15 48V EPS Stand-on Seated Full Electric Battery Operated Reach Stacker Truck Ce ISO

1. CURTIS controller, precise operation, maintenance-free,safe and reliable;
2. Vertical AC drive system, maintenance-free, safe and reliable;
3. 48V/400Ah industrial battery, large capacity, suitable for medium and high using frequency;
4. High performance hydraulic station, low noise, smooth operation, high efficiency;
5. Ergonomic handle design, buttons are easy to operate; suitable for left and right hand operation, better driving comfort;
6. EPS, labor saving; emergency reverse button, safer and more user-friendl;
7. Automatic deceleration when the fork is high, safe operation;
8. Full series of door frame can meet various needs of customers;
9. Fork with tilt function, more convenien;
10. Roof guard, headlight, etc.(Optional).

WHY CHOOSE US?
1.Strong production, research and development, after-sales capacity
We have 35, 000 square meters workshop and 100 R&D staff. We have been specializing in the forklift industry for more than 20 years. 20,000 units production capacity per year. OEM is also welcomed.

2.High quality source of raw materials and spare parts
Our spare parts and steel are all from well-known manufacturers at home and abroad with reliable quality. Besides, we are very professional in painting, welding and other production processes. Our products are both excellent in appearance and internal structure.

3.Competitive price and fast delivery
For standard forklift, normally we have them in store. If not, we can finish production within 1 week. Even for high mast and other non-standard forklift,we can finish production within 2 weeks. Our price is transparent and competitive. We are not the cheapest in the market, but we ensure you that our products worth every penny.

4.Professional technical guidance and use training
We have detailed operation instructions and video instructions for each product. If you have any question during the use, please feel free to contact us. We have professional personnel to answer them one by one.

5.Warranty and after-sales service
2000h or 2 years warranty time. Free parts change during warranty time.
Strict quality testing was conducted for each truck before shipping to ensure the safety of users.
In order to ensure our customer has a good using feeling, we send some spare parts for free with every forklift, eg: filters, seal, cylinder, etc.
In future, if customers need any spare parts, we will arrange shipping within 48h.

6.Complete product line
Diesel Forklift:1.5ton; 2ton; 2.5ton;3ton; 3.5ton; 3.8ton; 4ton; 4.5ton; 5ton; 6ton; 7ton; 8ton; 10ton; 12ton; 14ton; 15ton;16ton; 25ton; 28ton; 33ton; 42ton;45ton;48ton.
LPG&Gasoline Forklift :1.5ton; 2ton; 2.5ton;3ton; 3.5ton; 4ton; 5ton; 6ton; 7ton.
Electric Forklift: 1ton; 1.5ton; 2ton; 2.5ton;3ton; 3.5ton; 4ton; 5ton; 6ton.
Warehouse and material handling equipment: Manual hand pallet truck; electric pallet truck; electric pallet stacker; electric reach stacker; VNA(very narrow aisle) 3way or 4ways stacker; tow tractor; AGV equipments
Aerial platform:Scissor lifting platform 3.9M; 5.8M; 8M;10M;12M;14M
Rough terrain Off-road forklift and side forklift truck: 2ton to 12 ton

7.Logistics
It doesn't matter whether you have import qualification or not, we can solve the logistics problem for you. We have reliable logistics team and can send the goods directly to your warehouse if you need.
Also, we can do FOB, CIF and FCA term as you required.
